Decimal unitsĭimensions are allowed in the format of units in AutoCAD, such as 1.75 or 3.625. And also important note is Inches are considered as the default unit. In AUTOCAD As 6 inches are assumed to enter by 6. AutoCAD can display the smallest fraction that is 2~/”. Architectural units were supporting residential and commercial planning and construction drawings. Example: Twelve inches is automatically converted to 1 foot. Scientific: A measurement contains the length of 15.5 units, output as 1.5500E+01ĭimensions are allowed in the format of feet, inches, and fractional parts of an inch, such as 6′-11.5″.Fractional: A measurement contains the length of 15.5 units, output as 15 1/2.Engineering: A measurement contains a length of 15.5 units, output as 1’-3.5.”.Decimal: A measurement contains the length of 15.5 units, output as 15.5000.Architectural: A measurement contains the length of 15.5 units, output as 1’-3 1/2”.The linear units Including the following format settings

before you set the drawing units’ format, you must decide what drawing units to use. According to the drawing, one drawing unit be the same as in one millimeter, one inch, one mile or one meter. In AutoCAD, drawing units also used to measure the distance. Entering coordinates, distances, and angles at the Command line with the format of the values.predict the drawing for a distance or area with the format of the values.The following procedures will be affected by unit settings:
